Maximum planing width |
508mm |
|
Maximum planing thickness |
200mm |
|
Maximum depth of cut |
2.3mm |
|
Total Surface of work table |
1435mm x 508mm |
|
Cutterhead speed |
5000 rpm |
|
Cutterhead diameter |
80mm |
|
Number of knives |
4 |
|
Feed rates |
(4.8- |
|
Cuts per cm / inch |
41- |
|
Motor |
19 Amp |
|
Voltage |
230V. 1 phase. 50Hz |
|
Assembled dimensions (LxWxH)/weight |
1435 x 1016 x 1067mm / 377kgs |
|
Package dimensions (LxWxH)/weight |
972 x 737 x 1197mm / 390kgs |
